| PartNumber | N156DCE-GA1 |
| Znamka | Innolux |
| Velikost | 15.6 |
| Aplikacija | Laptop |
| Resolucija | 3840×2160 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 700:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | Innolux |
| panelni model | N156DCE-GA1 (CMN15E1) |
| velikost plošče | 15.6" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 3840(RGB)×2160, UHD, 283PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 344.218(W)×193.622(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 367.98(W)×218.8(H) ×3.2(D) mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način prikaza | AAS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 16/14 (Typ.)(Tr/Td) |
| barve zaslona | 16.7M 72% NTSC |
| tip svetilke | WLED , 15K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| slog oblike | Slim (PCBA Flat, T≤3.2mm) |
| aplikacija | Laptop |
| signalni vmesnik | eDP (4 Lanes) , eDP1.2 , 40 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
