| PartNumber | N156BGA-EB3 |
| Znamka | Innolux |
| Velikost | 15.6 |
| Aplikacija | Laptop |
| Resolucija | 1366×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 600:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka | Innolux |
| model | N156BGA-EB3 (CMN15FD) |
| velikost diagonale | 15.6 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1366(RGB)×768 [WXGA] 100PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 344.232(H)×193.536(V) mm |
| obris dim. | 350.73(H)×216.56(V) ×3.2(D) mm |
| območje okvirja | - |
| zdravljenje | Glare (Haze 0%), Hard coating (3H) |
| svetilnost | 220 cd/m² (Typ.) |
| kontrastno razmerje | 600:1 (Typ.) (TM) |
| smer pogleda | 6 o'clock |
| odzivni čas | 3/7 (Typ.)(Tr/Td) |
| vidni kot | 45/45/20/45 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 262K 45% NTSC |
| Izvor svetlobe | WLED , 15K hours , With LED Driver |
| slog oblike | Slim (PCBA Flat, T≤3.2mm) |
| namenjen za | Laptop |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
