| PartNumber | N116HSE-EA1 |
| Znamka | Innolux |
| Velikost | 11.6 |
| Aplikacija | NBPC |
| Resolucija | 1920×1080 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 700:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | CHIMEI INNOLUX |
| panelni model | N116HSE-EA1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 11.6 inch |
| resolucija | 1920(RGB)×1080 , FHD |
| način prikaza | AAS, Normally Black, Transmissive |
| aktivno območje | 256.32×144.18 mm |
| oris | 278×166×3.07 mm |
| slog oblike | Slim (PCBA Flat, Depth ≤3.2mm) |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193172% |
| odzivni čas | 14/11 (Typ.)(Tr/Td) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDEmbedded (LED Driver) |
| signalni vmesnik | eDP (2 Lanes), 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
