| PartNumber | N070ICE-G02 Rev.A2 |
| Znamka | Innolux |
| Velikost | 7.0 |
| Aplikacija | PAD |
| Resolucija | 800×1280 |
| Sestava | LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka plošče | INNOLUX |
| panelni model | N070ICE-G02 Rev.A2 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.0 inch |
| resolucija | 800(RGB)×1280 , WXGA |
| način prikaza | AAS, Normally Black, Transmissive |
| aktivno območje | 94.2×150.72 mm |
| oris | 103.5×162.22×4.51 mm |
| površino | |
| svetlost | |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193160% |
| odzivni čas | 11/9 (Typ.)(Tr/Td) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | MIPI (4 data lanes), 31 pins |
| vhodna napetost | 1.8/3.3V (Typ.)(VDDI/VCI) |
| aplikacija | PAD |
