| PartNumber | MG1561B01-2 |
| Znamka | CSOT |
| Velikost | 15.6 |
| Aplikacija | Digital Signage |
| Resolucija | 1920×1080 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 3000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| proizvajalec | CSOT |
| ime modela | MG1561B01-2 |
| velikost zaslona | 15.6 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1920(RGB)×1080 (FHD) 141PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 344.16 × 193.59 (H×V) |
| obris (mm) | 351.86 × 206.332 × 6.31 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare (Haze 25%), Hard coating (3H) |
| svetilnost | 250 cd/m² (Typ.) |
| kontrastno razmerje | 3000 : 1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| odgovor | 30 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | VA, Normally Black, Transmissive |
| barvna globina | 16.7M 72% NTSC |
| osvetlitev ozadja | WLED , 15K hours , With LED Driver |
| masa | 530g (Typ.) |
| uporablja za | Digital Signage |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (2 ch, 8-bit) , Connector 40 pins |
| napajanje z napetostjo | 12.0V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
