| PartNumber | MCG156FDLAAQNN-AN20 |
| Znamka | Kyocera |
| Velikost | 15.6 |
| Aplikacija | Industrial |
| Resolucija | 1920×1080 |
| Sestava | LTPS TFT-LCD , LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka plošče | Kyocera |
| velikost plošče | 15.6" |
| resolucija | 1920(RGB)×1080, FHD, 141PPI |
| prikazno območje | 344.16(W)×193.59(H) mm |
| velikost obrisa | 363.8(W)×215.9(H) ×9.8(D) mm |
| svetlost | 450 cd/m² (Typ.) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 16.2M 73% NTSC |
| pogostost | 60Hz |
| utež | 1.05/1.09Kgs (Typ./Max.) |
| panelni model | MCG156FDLAAQNN-AN20 |
| vrsta plošče | LTPS TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | 347.06(W)×196.49(H) mm |
| površino | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| način prikaza | AWV, Normally Black, Transmissive |
| odzivni čas | 13/12 (Typ.)(Tr/Td) |
| tip svetilke | WLED , 50K hours , With LED Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial |
