| PartNumber | M215HCA-L5Z |
| Znamka | Innolux |
| Velikost | 21.5 |
| Aplikacija | Desktop Monitor |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 4 |
| Vmesnik | LVDS |
| znamka plošče | Innolux |
| panelni model | M215HCA-L5Z |
| velikost plošče | 21.5" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1920(RGB)×1080, FHD, 102PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 476.064(W)×267.786(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 484.464(W)×284.486(H) ×13.4(D) mm |
| površino | Antiglare (Haze 25%), Hard coating (3H) |
| svetlost | 250 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način prikaza | AAS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 8/7 (Typ.)(Tr/Td) |
| barve zaslona | 16.7M 72% NTSC |
| tip svetilke | 4 strings WLED , 30K hours , Without Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | 1.82±0.18Kgs |
| aplikacija | Desktop Monitor |
| signalni vmesnik | LVDS (2 ch, 8-bit) , 30 pins Connector |
| vhodna napetost | 5.0V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
