| PartNumber | M101GWWF R0 |
| Znamka | IVO |
| Velikost | 10.1 |
| Aplikacija | Laptop |
| Resolucija | 1280×800 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | IVO |
| model | M101GWWF R0 |
| velikost diagonale | 10.1 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1280(RGB)×800 [WXGA] 149PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 216.96(H)×135.6(V) mm |
| obris dim. | 229.46(H)×149.1(V) ×4.56(D) mm |
| območje okvirja | - |
| zdravljenje | Glare (Haze 0%), Hard coating (3H) |
| svetilnost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | IPS, Normally Black, Transmissive |
| podpira barvo | 16.7M |
| Izvor svetlobe | WLED , 25K hours , With LED Driver |
| slog oblike | Slim (PCBA Bent, T≤3.0mm) |
| namenjen za | Laptop |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (1 ch, 8-bit) , 40 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| B101AW06 V4 | AUO | 10.1 | 1024×600 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| B101EVT05.0 | AUO | 10.1 | 1280×800 |
| B101EW02 V1 | AUO | 10.1 | 1280×720 |
| EJ101IA-01C | Innolux | 10.1 | 1280×800 |
| HV101WU1-1E3 | HYDIS | 10.1 | 1920×1200 |
| M101GWN9 R0 | IVO | 10.1 | 1024×600 |
| M101GWN9 R2 | IVO | 10.1 | 1024×600 |
| M101GWT9 R3 | IVO | 10.1 | 1024×600 |
| N101ICG-L21 Rev.B1 | Innolux | 10.1 | 1280×800 |
