| PartNumber | M090AWP4 R1 |
| Znamka | IVO |
| Velikost | 9.0 |
| Aplikacija | Outdoor High Brightn |
| Resolucija | 800×480 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 700:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | Parallel |
| proizvajalec | IVO |
| velikost zaslona | 9.0 inch |
| število slikovnih pik | 800(RGB)×480 (WVGA) 104PPI |
| aktivna površina (mm) | 198 × 112.08 (H×V) |
| površina okvirja (mm) | 200.2 × 114.28 (H×V) |
| svetilnost | 750 cd/m² (Typ.) |
| vidni kot | 70/70/50/70 (Typ.)(CR≥10) |
| dober pogled na | 6 o'clock |
| barvna globina | 262K 70% NTSC |
| masa | - |
| hitrost osveževanja | 60Hz |
| vrsto signala | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| maks. ocene | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| ime modela | M090AWP4 R1 |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 210.82 × 126.96 × 6.4 (H×V×D) |
| zdravljenje | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 700 : 1 (Typ.) (TM) |
| odgovor | 12 (Typ.)(Tr+Td) ms |
| način dela | TN, Normally White, Transmissive |
| osvetlitev ozadja | WLED , No Driver |
| uporablja za | Outdoor High Brightness Automotive Display |
| zaslon na dotik | Without |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| CLAA090NA02CW | CPT | 9.0 | 1024×600 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| EE090NA-01C | Innolux | 9.0 | 1280×800 |
| LTA090A220F | TOSHIBA | 9.0 | 800×480 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| T-55561D090J-LW-A-AAN | Kyocera | 9.0 | 800×480 |
| T-55562D090J-LW-A-AAN | Kyocera | 9.0 | 800×480 |
| TM090JDH01 | Tianma | 9.0 | 1280×800 |
| TX23D86VM0BAA | KOE | 9.0 | 1280×768 |
