| PartNumber | M080AWT8 R1 |
| Znamka | IVO |
| Velikost | 8.0 |
| Aplikacija | Automotive Display |
| Resolucija | 1024×600 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | IVO |
| model | M080AWT8 R1 |
| velikost diagonale | 8.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1024(RGB)×600 [WSVGA] 148PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 176.64(H)×99.36(V) mm |
| obris dim. | 192.8(H)×116.9(V) ×8.35(D) mm |
| območje okvirja | 178.84(H)×101.56(V) mm |
| zdravljenje | Antiglare |
| svetilnost | 670 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| smer pogleda | 6 o'clock |
| odzivni čas | 16 (Typ.)(Tr+Td) |
| vidni kot | 75/75/70/75 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 262K/16.7M 72% NTSC |
| Izvor svetlobe | WLED [3S7P] , 30K hours , W/O Driver |
| utež | 240g (Max.) |
| namenjen za | Automotive Display |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C |
