| PartNumber | LTN160HT02-001 |
| Znamka | Samsung |
| Velikost | 16.0 |
| Aplikacija | NBPC |
| Resolucija | 1920×1080 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | RGB LED |
| Vmesnik | LVDS |
| znamka plošče | SAMSUNG |
| panelni model | LTN160HT02-001 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 16.0 inch |
| resolucija | 1920(RGB)×1080 , FHD |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 353.28×198.72 mm |
| oris | 365×217 mm |
| slog oblike | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površino | Antiglare (Haze 40%), Hard coating (3H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K (6-bit), Adobe100% |
| odzivni čas | 8 (Typ.)(Tr+Td) |
| vidni kot | 75/75/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | RGB LEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (2 ch, 6-bit), 50 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
