| PartNumber | LTN156KT01-003 |
| Znamka | Samsung |
| Velikost | 15.6 |
| Aplikacija | NBPC |
| Resolucija | 1600×900 |
| Sestava | LCM |
| Svetlost | 250 |
| CR | 400:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | SAMSUNG |
| panelni model | LTN156KT01-003 2 Compatible model |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 15.6 inch |
| resolucija | 1600(RGB)×900 , HD+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 344.232×193.536 mm |
| oris | 359.3×209.5×5.8 mm |
| slog oblike | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površino | Antiglare (Haze 25%), Hard coating (3H) |
| svetlost | 250 cd/m² (Typ.) |
| kontrastno razmerje | 400:1 (Min.) |
| barve zaslona | 262K (6-bit), CIE193160% |
| odzivni čas | 16 (Typ.)(Tr+Td) |
| vidni kot | 55/55/45/45 (Min.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 8S8PWLEDEmbedded (LED Driver) |
| signalni vmesnik | eDP (1 Lane), 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
| B156XTN03.1 | AUO | 15.6 | 1366×768 |
| B156XW02 V2 HW4A | AUO | 15.6 | 1366×768 |
| LP156WD1-TLB4 | LG Display | 15.6 | 1600×900 |
| LP156WF3-SLB2 | LG Display | 15.6 | 1920×1080 |
| LTN156KT01-001 | Samsung | 15.6 | 1600×900 |
| LTN156KT01-003 | Samsung | 15.6 | 1600×900 |
| LTN156KT01-W01 | Samsung | 15.6 | 1600×900 |
| LTN156KT02-301 | Samsung | 15.6 | 1600×900 |
| LTN156KT06-801 | Samsung | 15.6 | 1600×900 |
| N156O6-L04 | Innolux | 15.6 | 1600×900 |
| B101EW02 V1 | AUO | 10.1 | 1280×720 |
| B116XTT01.1 | AUO | 11.6 | 1366×768 |
| BT140GW01 V.5 | Innolux | 14.0 | 1366×768 |
| LP101WH1-TLA3 | LG Display | 10.1 | 1366×768 |
| LP121X05-A2 | LG Display | 12.1 | 1024×768 |
| LP173WF1-TLB3 | LG Display | 17.3 | 1920×1080 |
| LTD089EXWF | TOSHIBA | 8.9 | 1280×768 |
| LTD121EX1S | TOSHIBA | 12.1 | 1280×768 |
| LTN141AT06-001 | Samsung | 14.1 | 1280×800 |
| N156HGE-LB1 | Innolux | 15.6 | 1920×1080 |
