| PartNumber | LTN141XB-L04 |
| Znamka | Samsung |
| Velikost | 14.1 |
| Aplikacija | NBPC |
| Resolucija | 1024×768 |
| Sestava | LCM |
| Svetlost | 185 |
| CR | 300:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | SAMSUNG |
| panelni model | LTN141XB-L04 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 14.1 inch |
| resolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 285.696×214.272 mm |
| oris | 299×240.6×5.5 mm |
| slog oblike | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površino | Antiglare (Haze 25%), Hard coating (3H) |
| svetlost | 185 cd/m² (Typ.) |
| kontrastno razmerje | 300:1 (Min.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFLEmbedded (Inverter) |
| signalni vmesnik | LVDS (1 ch, 6-bit), 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
| LTN141AT05-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT05-G03 | Samsung | 14.1 | 1280×800 |
| LTN141AT06-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT15-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-003 | Samsung | 14.1 | 1280×800 |
| LTN141BT06-002 | Samsung | 14.1 | 1440×900 |
| LTN141BT08-001 | Samsung | 14.1 | 1440×900 |
| LTN141W1-L09 | Samsung | 14.1 | 1280×800 |
| LTN141XB-L04 | Samsung | 14.1 | 1024×768 |
| B133XTN01.2 | AUO | 13.3 | 1366×768 |
| B140XW01 V0 | AUO | 14.0 | 1366×768 |
| B154EW02 V1 | AUO | 15.4 | 1280×800 |
| HSD173PUW1-A | HannStar | 17.3 | 1920×1080 |
| LM-DA53-22NTW | SANYO | 8.0 | 640×480 |
| LP129QE1-SPA1 | LG Display | 12.9 | 2560×1700 |
| LP150X08-TLAD | LG Display | 15.0 | 1024×768 |
| LP156WD1-TLD3 | LG Display | 15.6 | 1600×900 |
| N101BGE-L21 | Innolux | 10.1 | 1366×768 |
| N156O6-L04 | Innolux | 15.6 | 1600×900 |
