| PartNumber | LTN133YL01-F01 |
| Znamka | Samsung |
| Velikost | 13.3 |
| Aplikacija | NBPC |
| Resolucija | 3200×1800 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | SAMSUNG |
| panelni model | LTN133YL01-F01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 13.3 inch |
| resolucija | 3200RG(BW)×1800 , Quad-HD+ |
| način prikaza | PLS, Normally Black, Transmissive |
| aktivno območje | 293.44×165.06 mm |
| oris | 306.15×188.2 mm |
| slog oblike | Slim (PCBA Flat, Depth ≤3.2mm) |
| površino | |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193172% |
| odzivni čas | 16 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 11S5PWLEDEmbedded (LED Driver) |
| signalni vmesnik | eDP (4 Lanes), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
