| PartNumber | LTM236FL01 |
| Znamka | Samsung |
| Velikost | 23.6 |
| Aplikacija | DMPC |
| Resolucija | 3840×2160 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | SAMSUNG |
| panelni model | LTM236FL01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 23.6 inch |
| resolucija | 3840(RGB)×2160 , UHD |
| način prikaza | PLS, Normally Black, Transmissive |
| aktivno območje | 521.28×293.22 mm |
| oris | 544.8×320.5×11 mm |
| površino | Antiglare (Haze 25%), Hard coating (3H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), sRGB100% |
| odzivni čas | 14 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 4 stringsWLEDWithout Driver |
| signalni vmesnik | eDP (4 Lanes), 51 pins |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | DMPC |
