| PartNumber | LTI550HN16 |
| Znamka | SAMSUNG |
| Velikost | 55 |
| Aplikacija | Video Wall |
| Resolucija | 1920×1080 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 4000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| proizvajalec | SAMSUNG |
| ime modela | LTI550HN16 |
| velikost zaslona | 55 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1920(RGB)×1080 (FHD) 40PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 1209.6 × 680.4 (H×V) |
| obris (mm) | 1211.6 × 682.4 × 68.1 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare (Haze 25%), Hard coating (2H) |
| svetilnost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 4000 : 1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| odgovor | 8 (Typ.)(G to G) ms |
| dober pogled na | Symmetry |
| način dela | SVA, Normally Black, Transmissive |
| barvna globina | 16.7M 99% sRGB |
| osvetlitev ozadja | WLED , 50K hours , With LED Driver |
| spojni šiv | 2.0 mm (active to active seam) |
| uporablja za | Video Wall |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (2 ch, 8-bit) , Connector 51 pins |
| napajanje z napetostjo | 12.0V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
