| PartNumber | LTA550HW04 |
| Znamka | Samsung |
| Velikost | 55 |
| Aplikacija | LCTV |
| Resolucija | 1920×1080 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 4000:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | SAMSUNG |
| panelni model | LTA550HW04 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 55 inch |
| resolucija | 1920(RGB)×1080 , FHD |
| način prikaza | SVA, Normally Black, Transmissive |
| aktivno območje | 1209.6×680.4 mm |
| oris | 1229.4×704.2 mm |
| površino | Antiglare |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 4000:1 (Typ.) |
| barve zaslona | 1.07B (8-bit + Dithering), CIE193170% |
| odzivni čas | 6 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 120Hz |
| tip svetilke | 2 stringsWLEDWithout Driver |
| signalni vmesnik | LVDS (4 ch, 10-bit), 92 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | LCTV |
