| PartNumber | LQ197V1LC17 |
| Znamka | SHARP |
| Velikost | 19.7 |
| Aplikacija | LCTV |
| Resolucija | 640×480 |
| Sestava | LCM |
| Svetlost | 260 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | SHARP |
| panelni model | LQ197V1LC17 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 19.7 inch |
| resolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 401.28×298.8 mm |
| oris | 448.1×340.1 mm |
| površino | Hard coating (2H) |
| svetlost | 260 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 60/60/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 4 pcsCCFLWithout Driver |
| signalni vmesnik | LVDS (1 ch, 6-bit), 20 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | LCTV |
