| PartNumber | LQ196A1LZ12 |
| Znamka | SHARP |
| Velikost | 19.6 |
| Aplikacija | GM |
| Resolucija | 1600×1200 |
| Sestava | LCM |
| Svetlost | |
| CR | |
| Barve | 16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | SHARP |
| panelni model | LQ196A1LZ12 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 19.6 inch |
| resolucija | 1600(RGB)×1200 , UXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 398.4×298.8 mm |
| površino | |
| svetlost | |
| kontrastno razmerje | |
| barve zaslona | 16.2M (6-bit + FRC) |
| odzivni čas | 15/10 (Typ.)(Tr/Td) |
| vidni kot | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | WLED |
| signalni vmesnik | LVDS (2 ch, 8-bit) |
| rohs: | |
| aplikacija | GM |
