| PartNumber | LQ043T1LX01A |
| Znamka | SHARP |
| Velikost | 4.3 |
| Aplikacija | MPH |
| Resolucija | 540×960 |
| Sestava | LCM |
| Svetlost | 500 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MDDI/MIPI |
| znamka plošče | SHARP |
| panelni model | LQ043T1LX01A |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 4.3 inch |
| resolucija | 540(RGB)×960 , qHD |
| način prikaza | ASV, Normally Black, Transmissive |
| aktivno območje | 53.46×95.04 mm |
| oris | 58.54×105.7 mm |
| površino | Hard coating (3H) |
| svetlost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193170% |
| odzivni čas | 35 (Max.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 10S1PWLEDWithout Driver |
| signalni vmesnik | MDDI/MIPI, 25 pins |
| vhodna napetost | 1.8/3.1V (Typ.)(IOVDD/AVDD) |
| aplikacija | MPH |
