| PartNumber | LQ038Q5DR01 |
| Znamka | SHARP |
| Velikost | 3.8 |
| Aplikacija | CNS |
| Resolucija | 320×240 |
| Sestava | LCM |
| Svetlost | 450 |
| CR | 100:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TTL |
| znamka plošče | SHARP |
| panelni model | LQ038Q5DR01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 3.8 inch |
| resolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 78.72×53.64 mm |
| oris | 117.6×69.45 mm |
| površino | Antiglare, Antireflection |
| svetlost | 450 cd/m² (Typ.) |
| kontrastno razmerje | 100:1 (Min.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 30/50 (Typ.)(Tr/Td) |
| vidni kot | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.)(VCC) |
| aplikacija | CNS |
