| PartNumber | LP171WU6-TLB1 |
| Znamka | LG Display |
| Velikost | 17.1 |
| Aplikacija | NBPC |
| Resolucija | 1920×1200 |
| Sestava | LCM |
| Svetlost | 275 |
| CR | 600:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | LG Display |
| panelni model | LP171WU6-TLB1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 17.1 inch |
| resolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 367.2×229.5 mm |
| slog oblike | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| površino | Antiglare |
| svetlost | 275 cd/m² (Typ.) |
| kontrastno razmerje | 600:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 16 (Typ.)(Tr+Td) |
| vidni kot | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 14S6PWLEDWithout Driver |
| signalni vmesnik | LVDS (2 ch, 6-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
