| PartNumber | LP156WF3-SLB1 |
| Znamka | LG Display |
| Velikost | 15.6 |
| Aplikacija | NBPC |
| Resolucija | 1920×1080 |
| Sestava | LCM |
| Svetlost | 210 |
| CR | 800:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | RGB LED |
| Vmesnik | LVDS |
| znamka plošče | LG Display |
| panelni model | LP156WF3-SLB1 2 Compatible model |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 15.6 inch |
| resolucija | 1920(RGB)×1080 , FHD |
| način prikaza | S-IPS, Normally Black, Transmissive |
| aktivno območje | 344.16×193.59 mm |
| oris | 359.3×212.1×7.2 mm |
| slog oblike | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 210 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 1.07B (10-bit), CIE1931110% |
| odzivni čas | 30 (Typ.)(Tr+Td); 15 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | RGB LEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (2 ch, 10-bit), 50 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
