| PartNumber | LM140LF2L05 |
| Znamka | PANDA |
| Velikost | 14.0 |
| Aplikacija | Laptop |
| Resolucija | 1920×1080 |
| Sestava | Oxide TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | PANDA |
| panelni model | LM140LF2L05 (NCP0062) |
| velikost plošče | 14.0" |
| vrsta plošče | Oxide TFT-LCD, LCM |
| resolucija | 1920(RGB)×1080, FHD, 157PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 309.312(W)×173.988(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 315.81(W)×197.57(H) ×3(D) mm |
| površino | Hard coating |
| svetlost | 250 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način prikaza | PAS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| barve zaslona | 16.7M 45% NTSC |
| tip svetilke | WLED , 15K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| slog oblike | Slim (PCBA Flat, T≤3.2mm) |
| aplikacija | Laptop |
| signalni vmesnik | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
