| PartNumber | LH300WQ1-ED01 |
| Znamka | LG Display |
| Velikost | 3.0 |
| Aplikacija | MPH |
| Resolucija | 240×400 |
| Sestava | OLED |
| Svetlost | 210 |
| CR | 2000:1 |
| Barve | 65K/262K |
| Osvetlitev ozadja | self |
| Vmesnik | CPU/RGB/SPI |
| znamka plošče | LG Display |
| panelni model | LH300WQ1-ED01 |
| vrsta plošče | AM-OLED , OLED |
| velikost plošče | 3.0 inch |
| resolucija | 240(RGB)×400 , WQVGA |
| aktivno območje | 38.88×64.8 mm |
| oris | 44×74.6 mm |
| površino | Hard coating |
| svetlost | 210 cd/m² (Typ.) |
| kontrastno razmerje | 2000 : 1 (Min.) |
| barve zaslona | 65K/262K , CIE193185% |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| signalni vmesnik | 8/9/16/18-bit 6800/8080 parallel, 6/16/18-bit RGB, SPI, 40 pins |
| vhodna napetost | 2.8/2.8/3.7V (Typ.)(VDD/VCC/VBATT) |
| aplikacija | MPH |
