| PartNumber | LD470DXS-SCB1 |
| Znamka | LG Display |
| Velikost | 47 |
| Aplikacija | DID |
| Resolucija | 1366×768 |
| Sestava | LCM |
| Svetlost | 500 |
| CR | 1400:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | LG Display |
| panelni model | LD470DXS-SCB1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 47 inch |
| resolucija | 1366(RGB)×768 , WXGA |
| način prikaza | S-IPS, Normally Black, Transmissive |
| aktivno območje | 1039.87×584.64 mm |
| oris | 1046.8×591.6×50.5 mm, Videowall Seam 6.9 mm |
| površino | Antiglare (Haze 10%), Hard coating (3H) |
| svetlost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 1400:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193172% |
| odzivni čas | 12 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (1 ch, 8-bit), 30 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | DID |
