| PartNumber | LD420WUB-SBA1 |
| Znamka | LG Display |
| Velikost | 42 |
| Aplikacija | PID |
| Resolucija | 1920×1080 |
| Sestava | LCM |
| Svetlost | 700 |
| CR | 1000:1 |
| Barve | 16.7M/1.06B |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | LG Display |
| panelni model | LD420WUB-SBA1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 42 inch |
| resolucija | 1920(RGB)×1080 , FHD |
| način prikaza | S-IPS, Normally Black, Transmissive |
| aktivno območje | 930.24×523.26 mm |
| oris | 956.4×549.4×54.5 mm, Videowall Seam 26.2 mm |
| površino | Antiglare (Haze 10%), Hard coating (3H) |
| svetlost | 700 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M/1.06B (8-bit / 8-bit + Dithering) |
| odzivni čas | 9 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | CCFLEmbedded (Inverter) |
| signalni vmesnik | LVDS (2 ch, 8/10-bit), 51 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | PID |
