| PartNumber | LC470EUH-PEF1 |
| Znamka | LG Display |
| Velikost | 47 |
| Aplikacija | LCTV |
| Resolucija | 1920×1080 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 1600:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | EPI |
| znamka plošče | LG Display |
| panelni model | LC470EUH-PEF1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 47 inch |
| resolucija | 1920(RGB)×1080 , FHD |
| način prikaza | S-IPS, Normally Black, Transmissive |
| aktivno območje | 1039.68×584.82 mm |
| oris | 1059.48×616.21 mm |
| površino | Antiglare (Haze 1%), Hard coating (2H) |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 1600:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193172% |
| odzivni čas | 8/10 (Typ.)(Tr/Td) |
| vidni kot | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| pogostost | 120Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | EPI, 100 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | LCTV |
