| PartNumber | LC156LF1L03 |
| Znamka | PANDA |
| Velikost | 15.6 |
| Aplikacija | Laptop |
| Resolucija | 1920×1080 |
| Sestava | Oxide TFT-LCD, CELL |
| Svetlost | |
| CR | - |
| Barve | 262K |
| Osvetlitev ozadja | No |
| Vmesnik | eDP |
| znamka plošče | PANDA |
| panelni model | LC156LF1L03 |
| velikost plošče | 15.6" |
| vrsta plošče | Oxide TFT-LCD, CELL |
| resolucija | 1920(RGB)×1080, FHD, 141PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 344.16(W)×193.59(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 354.36(W)×204.04(H) ×1.076(D) mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 0 cd/m² |
| kontrastno razmerje | - |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način prikaza | FFS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| globina stekla | 0.40+0.40 mm |
| transmisivnost | 6.5% (Typ.) |
| barve zaslona | 262K 47% NTSC |
| tip svetilke | No B/L , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| voznik ic | COGBuilt-in 4 source + 2 gate chips |
| slog oblike | - |
| aplikacija | Laptop |
| signalni vmesnik | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
