| PartNumber | LA123WF4-SR08 |
| Znamka | LG Display |
| Velikost | 12.3 |
| Aplikacija | Automotive Display |
| Resolucija | 1920×720 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 8S6P |
| Vmesnik | |
| proizvajalec | LG Display |
| ime modela | LA123WF4-SR08 |
| velikost zaslona | 12.3 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1920(RGB)×720 167PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 292.032 × 109.512 (H×V) |
| obris (mm) | 310 × 128 × 10.75 (H×V×D) |
| površina okvirja (mm) | 296.03 × 113.5 (H×V) |
| zdravljenje | Hard coating |
| svetilnost | 600 cd/m² (Min.) |
| kontrastno razmerje | 800 : 1 (Min.) (TM) |
| vidni kot | 89/89/89/89 (Min.)(CR≥10) |
| odgovor | 30 (Max.)(G to G); 30 (Typ.)(MPRT) ms |
| dober pogled na | Symmetry |
| način dela | IPS, Normally Black, Transmissive |
| barvna globina | 16.7M 77% NTSC |
| osvetlitev ozadja | 8S6P WLED , 10K hours , No Driver |
| masa | - |
| uporablja za | Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
