| PartNumber | LA123WF4-SR03 |
| Znamka | LG Display |
| Velikost | 12.3 |
| Aplikacija | Automotive Display |
| Resolucija | 1920×720 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | RSDS |
| znamka | LG Display |
| model | LA123WF4-SR03 |
| velikost diagonale | 12.3 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1920(RGB)×720 167PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 292.032(H)×109.512(V) mm |
| obris dim. | 310(H)×128(V) ×10.75(D) mm |
| območje okvirja | 296.03(H)×113.5(V) mm |
| zdravljenje | Hard coating |
| svetilnost | 600 cd/m² (Min.) |
| kontrastno razmerje | 800:1 (Min.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| vidni kot | 89/89/89/89 (Min.)(CR≥10) |
| način delovanja | IPS, Normally Black, Transmissive |
| podpira barvo | 16.7M 77% NTSC |
| Izvor svetlobe | WLED [11S4P] , 10K hours , W/O Driver |
| utež | 385/400g (Typ./Max.) |
| namenjen za | Automotive Display |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | RSDS (2 Channel) , 110 pins FPC |
| napajanje | 3.3/13.0V (Typ.)(VCC/VDD) |
| okolju | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
