| PartNumber | KCS3224ASTT-X6 |
| Znamka | Kyocera |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | CSTN-LCD , LCM |
| Svetlost | |
| CR | 25:1 |
| Barve | Color |
| Osvetlitev ozadja | - |
| Vmesnik | Parallel |
| znamka | Kyocera |
| velikost diagonale | 5.7 inch |
| slikovnih pik | 320(RGB)×240 [QVGA] 70PPI |
| aktivno območje | 115.2(H)×86.4(V) mm |
| svetilnost | - |
| smer pogleda | - |
| vidni kot | 50/50/30/30 (Typ.)(CR≥2) |
| podpira barvo | Color |
| utež | - |
| hitrost sličic | 75Hz |
| tip vmesnika | Parallel Data (1ch, 8-bit) Connector |
| napajanje | 5.0V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | KCS3224ASTT-X6 |
| vrsta | CSTN-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | - |
| kontrastno razmerje | 25:1 (Typ.) (TM) |
| odzivni čas | 220/110 (Typ.)(Tr/Td) |
| način delovanja | STN, Normally Black, Transmissive |
| Izvor svetlobe | |
| namenjen za | Industrial |
| plošča na dotik | Without |
