| PartNumber | KCG057QV1DC-G00 |
| Znamka | Kyocera |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | CSTN-LCD , LCM |
| Svetlost | |
| CR | 55:1 |
| Barve | Color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | |
| znamka plošče | Kyocera |
| velikost plošče | 5.7" |
| resolucija | 320(RGB)×240, QVGA, 70PPI |
| prikazno območje | 115.2(W)×86.4(H) mm |
| svetlost | - |
| vidni kot | 50/50/20/35 (Typ.)(CR≥2) |
| najboljši pogled na | - |
| barve zaslona | Color |
| utež | - |
| panelni model | KCG057QV1DC-G00 |
| vrsta plošče | CSTN-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| kontrastno razmerje | 55:1 (Typ.) (TM) |
| način prikaza | STN, Normally Black, Transmissive |
| odzivni čas | 180/170 (Typ.)(Tr/Td) |
| tip svetilke | CCFL |
| aplikacija | Industrial |
