| PartNumber | HV056WX2-100 |
| Znamka | HYDIS |
| Velikost | 5.6 |
| Aplikacija | UMPC |
| Resolucija | 1280×800 |
| Sestava | Assembly |
| Svetlost | 220 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | HYDIS |
| panelni model | HV056WX2-100 |
| vrsta plošče | a-Si TFT-LCD , Assembly |
| velikost plošče | 5.6 inch |
| resolucija | 1280(RGB)×800 , WXGA |
| aktivno območje | 120.96×75.6 mm |
| oris | 158×90.3 mm |
| površino | Glare (Haze 0%), Hard coating (2H) |
| svetlost | 220 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193145% |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| signalni vmesnik | LVDS (1 ch, 6-bit), 25 pins |
| aplikacija | UMPC |
| BP070WX1-100 | BOE | 7.0 | 1280×800 |
| CLAA070NC0DCW | CPT | 7.0 | 1024×600 |
| CLAA070NP01 | CPT | 7.0 | 1024×600 |
| HV056WX2-100 | HYDIS | 5.6 | 1280×800 |
| LD070WS2-SL02 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL05 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| LT080EE04000 | TOSHIBA | 8.0 | 1600×768 |
| N070ICG-LD1 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD4 | Innolux | 7.0 | 1280×800 |
