| PartNumber | HSD150GXN1-A00-C00 |
| Znamka | HannStar |
| Velikost | 15.0 |
| Aplikacija | Industrial |
| Resolucija | 1024×768 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 700:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | HannStar |
| velikost diagonale | 15.0 inch |
| slikovnih pik | 1024(RGB)×768 [XGA] 85PPI |
| aktivno območje | 304.128(H)×228.096(V) mm |
| območje okvirja | 307.4(H)×231.3(V) mm |
| svetilnost | 250 cd/m² (Typ.) |
| smer pogleda | - |
| vidni kot | 80/80/60/80 (Typ.)(CR≥10) |
| podpira barvo | 262K/16.2M 60% NTSC |
| utež | 1.20Kgs (Max.) |
| hitrost sličic | 60Hz |
| tip vmesnika | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
| model | HSD150GXN1-A00-C00 |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 326.5(H)×253.5(V) ×12.7(D) mm |
| zdravljenje | - |
| kontrastno razmerje | 700:1 (Typ.) (TM) |
| odzivni čas | 12 (Typ.)(Tr+Td) |
| način delovanja | TN, Normally White, Transmissive |
| Izvor svetlobe | WLED , 30K hours , With LED Driver |
| namenjen za | Industrial |
| plošča na dotik | Embeded Touch |
| G150XTN01.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| G150XVN01.0 | AUO | 15.0 | 1024×768 |
| HSD150PX16-A | HannStar | 15.0 | 1024×768 |
| LC150X01-A3K2 | LG Display | 15.0 | 1024×768 |
| LQ150X1LG92 | SHARP | 15.0 | 1024×768 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18C | NLT | 15.0 | 1024×768 |
| NL10276BC30-39 | NLT | 15.0 | 1024×768 |
| T150XG01 V2 | AUO | 15.0 | 1024×768 |
