| PartNumber | HSD123KPW2-D10 |
| Znamka | HannStar |
| Velikost | 12.3 |
| Aplikacija | Automotive Display |
| Resolucija | 1920×720 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1100:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 11S4P |
| Vmesnik | |
| proizvajalec | HannStar |
| ime modela | HSD123KPW2-D10 |
| velikost zaslona | 12.3 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1920(RGB)×720 167PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 292.032 × 109.512 (H×V) |
| obris (mm) | 308.1 × 130 × 15.6 (H×V×D) |
| površina okvirja (mm) | 294.8 × 112.1 (H×V) |
| zdravljenje | Antiglare |
| svetilnost | 850 cd/m² (Typ.) |
| kontrastno razmerje | 1100 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | 14/16 (Max.)(Tr/Td) ms |
| dober pogled na | Symmetry |
| način dela | IPS Pro, Normally Black, Transmissive |
| barvna globina | 16.7M 100% sRGB |
| osvetlitev ozadja | 11S4P WLED , 30K hours , No Driver |
| masa | 515/540g (Typ./Max.) |
| uporablja za | Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
