| PartNumber | HSD123KPW1-A30 |
| Znamka | HannStar |
| Velikost | 12.3 |
| Aplikacija | Automotive Display |
| Resolucija | 1920×720 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 11S4P |
| Vmesnik | |
| znamka plošče | HannStar |
| velikost plošče | 12.3" |
| resolucija | 1920(RGB)×720, 167PPI |
| prikazno območje | 292.032(W)×109.512(H) mm |
| velikost obrisa | 308.1(W)×130(H) ×15.6(D) mm |
| svetlost | 850 cd/m² (Typ.) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 16.7M 71% NTSC |
| pogostost | 60Hz |
| utež | 520g (Typ.) |
| panelni model | HSD123KPW1-A30 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | 294.8(W)×112.1(H) mm |
| površino | Antiglare |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| način prikaza | IPS Pro, Normally Black, Transmissive |
| odzivni čas | 17/18 (Typ.)(Tr/Td) |
| tip svetilke | 11S4P WLED , 30K hours , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Automotive Display |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
