| PartNumber | HSD121KXN1-A10-0299 |
| Znamka | HannStar |
| Velikost | 12.1 |
| Aplikacija | Automotive Display |
| Resolucija | 1024×768 |
| Sestava | CELL, a-Si TFT-LCD |
| Svetlost | |
| CR | 900:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | LVDS |
| proizvajalec | HannStar |
| ime modela | HSD121KXN1-A10-0299 |
| velikost zaslona | 12.1 inch |
| vrsto zaslona | CELL, a-Si TFT-LCD |
| število slikovnih pik | 1024(RGB)×768 (XGA) 105PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 245.76 × 184.32 (H×V) |
| obris (mm) | 256.18 × 196.9 × 1.27 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 0 cd/m² |
| kontrastno razmerje | 900 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | 30 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | IPS Pro, Normally Black, Transmissive |
| debelina stekla | 0.50+0.50 mm |
| transmisivnost | - |
| barvna globina | 262K/16.7M 70% NTSC |
| osvetlitev ozadja | No B/L , No Driver |
| masa | 160/180g (Typ./Max.) |
| uporablja za | Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
