| PartNumber | HSD104KXN1-A20 |
| Znamka | HannStar |
| Velikost | 10.4 |
| Aplikacija | Automotive Display |
| Resolucija | 1024×768 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 900:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| proizvajalec | HannStar |
| ime modela | HSD104KXN1-A20 |
| velikost zaslona | 10.4 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1024(RGB)×768 (XGA) 123PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 211.2 × 158.4 (H×V) |
| obris (mm) | - |
| svetilnost | - |
| kontrastno razmerje | 900 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | - |
| dober pogled na | Symmetry |
| način dela | IPS Pro, Normally Black, Transmissive |
| barvna globina | 262K/16.2M |
| osvetlitev ozadja | WLED |
| masa | - |
| uporablja za | Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
