| PartNumber | HSD104KXN1-A10 |
| Znamka | HannStar |
| Velikost | 10.4 |
| Aplikacija | Automotive Display |
| Resolucija | 1024×768 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 900:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | 4S8P |
| Vmesnik | |
| proizvajalec | HannStar |
| ime modela | HSD104KXN1-A10 |
| velikost zaslona | 10.4 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1024(RGB)×768 (XGA) 123PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 211.2 × 158.4 (H×V) |
| obris (mm) | 236 × 174.3 × 7 (H×V×D) |
| površina okvirja (mm) | 213.2 × 160.4 (H×V) |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 600 cd/m² (Typ.) |
| kontrastno razmerje | 900 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | 30 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | IPS Pro, Normally Black, Transmissive |
| barvna globina | 262K/16.2M |
| osvetlitev ozadja | 4S8P WLED , 30K hours , No Driver |
| masa | 316g |
| uporablja za | Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| G104XVN01.0 | AUO | 10.4 | 1024×768 |
| G6481L-FF | CITIZEN | 10.4 | 640×480 |
| LM64C35P | SHARP | 10.4 | 640×480 |
| LQ104S1DG61 | SHARP | 10.4 | 800×600 |
| LQ104V1LG92 | SHARP | 10.4 | 640×480 |
| LQ10D341 | SHARP | 10.4 | 640×480 |
| LTM10C306Y | TOSHIBA | 10.4 | 1024×768 |
| LTN104S2-L01 | Samsung | 10.4 | 800×600 |
| NL8060BC26-17 | NLT | 10.4 | 800×600 |
| TX26D02VM1CAA | KOE | 10.4 | 640×480 |
