| PartNumber | HSD070JDW6-A00 |
| Znamka | HannStar |
| Velikost | 7.0 |
| Aplikacija | Automotive Display |
| Resolucija | 800×480 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | HannStar |
| velikost diagonale | 7.0 inch |
| slikovnih pik | 800(RGB)×480 [WVGA] 133PPI |
| aktivno območje | 152.4(H)×91.44(V) mm |
| območje okvirja | 154.4(H)×93.44(V) mm |
| svetilnost | 1000 cd/m² (Typ.) |
| smer pogleda | Symmetry |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| podpira barvo | 16.7M 70% NTSC |
| utež | 153±10g |
| hitrost sličic | 60Hz |
| model | HSD070JDW6-A00 |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 165(H)×104.07(V) ×8.5(D) mm |
| zdravljenje | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| način delovanja | IPS Pro, Normally Black, Transmissive |
| Izvor svetlobe | WLED [7S4P] , 30K hours , W/O Driver |
| namenjen za | Automotive Display |
| plošča na dotik | Without |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| AA070ME01 | Mitsubishi | 7.0 | 800×480 |
| AC070MD01 | Mitsubishi | 7.0 | 800×480 |
| CLAA070NJ01CW | CPT | 7.0 | 1024×600 |
| LB070WQ7-TD02 | LG Display | 7.0 | 480×234 |
| LB070WV4-SD01 | LG Display | 7.0 | 800×480 |
| LB070WV4-TD02 | LG Display | 7.0 | 800×480 |
| LQ070Y5DR04 | SHARP | 7.0 | 800×480 |
| TD070WGCB2 | TPO | 7.0 | 854×480 |
| TX18D37VM0AQA | KOE | 7.0 | 800×480 |
