| PartNumber | H466TAN01.1 |
| Znamka | AUO |
| Velikost | 4.7 |
| Aplikacija | MPH |
| Resolucija | 720×1280 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No B/L |
| Vmesnik | |
| znamka plošče | AUO |
| panelni model | H466TAN01.1 |
| vrsta plošče | LTPS TFT-LCD , CELL |
| velikost plošče | 4.7 inch |
| resolucija | 720(RGB)×1280 , WXGA |
| način prikaza | AHVA, Normally Black, Transmissive |
| aktivno območje | 58.104×103.296 mm |
| oris | 60.9×111.87 mm |
| površino | Hard coating |
| globina stekla | 0.17+0.17 mm |
| transmisivnost | 3.9% (Typ.)(with Polarizer) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193166% |
| odzivni čas | 35 (Max.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| voznik ic | COG Built-in NT35590 |
| aplikacija | MPH |
