| PartNumber | GV185FHM-N10-DM30 |
| Znamka | BOE |
| Velikost | 18.5 |
| Aplikacija | Industrial |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 11S4P |
| Vmesnik | LVDS |
| znamka plošče | BOE |
| panelni model | GV185FHM-N10-DM30 |
| velikost plošče | 18.5" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1920(RGB)×1080, FHD, 119PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 408.96(W)×230.04(H) mm |
| odprtina okvirja | 410.96(W)×232.04(H) mm |
| velikost obrisa | 430.4(W)×254.6(H) ×12.5(D) mm |
| površino | Antiglare (Haze 25%), Hard coating (3H) |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način prikaza | ADS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| barve zaslona | 16.7M 70% NTSC |
| tip svetilke | 11S4P WLED , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | 1.80Kgs (Typ.) |
| aplikacija | Industrial |
| signalni vmesnik | LVDS (2 ch, 8-bit) , 30 pins Connector |
| vhodna napetost | 5.0V (Typ.) |
| okolju | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
