| PartNumber | GV185FHM-N10-3M30 |
| Znamka | BOE |
| Velikost | 18.5 |
| Aplikacija | Industrial |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1200:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | BOE |
| model | GV185FHM-N10-3M30 |
| velikost diagonale | 18.5 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1920(RGB)×1080 [FHD] 119PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 408.96(H)×230.04(V) mm |
| obris dim. | 430.4(H)×254.6(V) ×12.5(D) mm |
| območje okvirja | 410.96(H)×232.04(V) mm |
| zdravljenje | Antiglare (Haze 25%), Hard coating (3H) |
| svetilnost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 1200:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | ADS, Normally Black, Transmissive |
| podpira barvo | 16.7M 70% NTSC |
| Izvor svetlobe | WLED [11S4P] , With LED Driver |
| utež | 1.80Kgs (Typ.) |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (2 ch, 8-bit) , 30 pins Connector |
| napajanje | 5.0V (Typ.) |
| okolju | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
