| PartNumber | GV101WXB-NN0-3GP0 |
| Znamka | BOE |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1280×800 |
| Sestava | a-Si TFT-LCD, CELL |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | LVDS |
| znamka plošče | BOE |
| panelni model | GV101WXB-NN0-3GP0 |
| velikost plošče | 10.1" |
| vrsta plošče | a-Si TFT-LCD, CELL |
| resolucija | 1280(RGB)×800, WXGA, 149PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 216.96(W)×135.6(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 221.96(W)×144.43(H) ×1.06(D) mm |
| površino | Without Polarizer, Hard coating |
| svetlost | 0 cd/m² |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| način prikaza | ADS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| barve zaslona | 16.7M 50% NTSC |
| tip svetilke | No B/L |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| voznik ic | COG Built-in 2 source chips |
| teža plošče | - |
| aplikacija | Industrial |
| signalni vmesnik | LVDS (1 ch, 8-bit) , 40 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
