| PartNumber | GT101WSM-N10 |
| Znamka | BOE |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1024×600 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 4 |
| Vmesnik | |
| znamka plošče | BOE |
| velikost plošče | 10.1" |
| resolucija | 1024(RGB)×600, WSVGA, 117PPI |
| prikazno območje | 222.72(W)×125.28(H) mm |
| velikost obrisa | 235(W)×143(H) mm |
| svetlost | 350 cd/m² (Typ.) |
| vidni kot | 70/70/0/60 (Typ.)(CR≥10) |
| najboljši pogled na | - |
| barve zaslona | 262K/16.7M 50% NTSC |
| pogostost | 60Hz |
| utež | 180g (Typ.) |
| panelni model | GT101WSM-N10 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | 225.92(W)×128.48(H) mm |
| površino | - |
| kontrastno razmerje | 500:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 20 (Typ.)(Tr+Td) |
| tip svetilke | 4 strings WLED , With LED Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial |
