| PartNumber | GT080S0M-N11-1QP0 |
| Znamka | BOE |
| Velikost | 8.0 |
| Aplikacija | Industrial |
| Resolucija | 800×600 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 4S5P |
| Vmesnik | |
| znamka plošče | BOE |
| velikost plošče | 8.0" |
| resolucija | 800(RGB)×600, SVGA, 125PPI |
| prikazno območje | 162(W)×121.5(H) mm |
| velikost obrisa | 183(W)×141(H) ×5.9(D) mm |
| svetlost | 250 cd/m² (Typ.) |
| vidni kot | 75/75/75/75 (Typ.)(CR≥10) |
| najboljši pogled na | - |
| barve zaslona | 262K/16.7M 50% NTSC |
| pogostost | 60Hz |
| utež | - |
| panelni model | GT080S0M-N11-1QP0 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | 164.8(W)×124.3(H) mm |
| površino | Antiglare |
| kontrastno razmerje | 500:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 20 (Typ.)(Tr+Td) |
| tip svetilke | 4S5P WLED , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial |
| A080SN03 V2 | AUO | 8.0 | 800×600 |
| AT080TN03 V.1 | Innolux | 8.0 | 800×480 |
| B080UAN01.2 | AUO | 8.0 | 1200×1920 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| EJ080NA-04B | Innolux | 8.0 | 1024×768 |
| LD080UX1-SMA2 | LG Display | 8.0 | 1200×1600 |
| LQ080V3DG01 | SHARP | 8.0 | 640×480 |
| LQ080Y5DG02 | SHARP | 8.0 | 800×480 |
| LQ080Y5DW03 | SHARP | 8.0 | 800×480 |
| LSL080AL02-002 | Samsung | 8.0 | 800×1280 |
