| PartNumber | GT070WVM-N10-3GP0 |
| Znamka | BOE |
| Velikost | 7.0 |
| Aplikacija | Industrial |
| Resolucija | 800×480 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 600:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka plošče | BOE |
| velikost plošče | 7.0" |
| resolucija | 800(RGB)×480, WVGA, 134PPI |
| prikazno območje | 154.08(W)×85.92(H) mm |
| velikost obrisa | 164.9(W)×100(H) ×6(D) mm |
| svetlost | 500 cd/m² (Typ.) |
| vidni kot | 75/75/60/75 (Typ.)(CR≥10) |
| najboljši pogled na | - |
| barve zaslona | 262K/16.7M 50% NTSC |
| pogostost | 60Hz |
| utež | 133±5g |
| panelni model | GT070WVM-N10-3GP0 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | 157.08(W)×89.33(H) mm |
| površino | Antiglare (Haze 25%), Hard coating (3H) |
| kontrastno razmerje | 600:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| tip svetilke | WLED , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial |
