| PartNumber | G270ZAN01.3 |
| Znamka | AUO |
| Velikost | 27.0 |
| Aplikacija | Industrial Medical I |
| Resolucija | 3840×2160 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 10S8P |
| Vmesnik | eDP |
| proizvajalec | AUO |
| ime modela | G270ZAN01.3 |
| velikost zaslona | 27.0 inch |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| število slikovnih pik | 3840(RGB)×2160 (UHD) 163PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 596.16 × 335.34 (H×V) |
| obris (mm) | 630 × 368.2 × 19.8 (H×V×D) |
| površina okvirja (mm) | 602.0 × 340.4 (H×V) |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| odgovor | 16/25 (Typ./Max.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | AHVA, Normally Black, Transmissive |
| barvna globina | 16.7M 99% Adobe RGB |
| osvetlitev ozadja | 10S8P WLED , 30K hours , No Driver |
| masa | 3.30Kgs (Typ.) |
| uporablja za | Industrial Medical Imaging |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector |
| napajanje z napetostjo | 12.0V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
