| PartNumber | G238HCJ-L01 |
| Znamka | Innolux |
| Velikost | 23.8 |
| Aplikacija | Industrial |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | Innolux |
| model | G238HCJ-L01 |
| velikost diagonale | 23.8 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1920(RGB)×1080 [FHD] 92PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 527.04(H)×296.46(V) mm |
| obris dim. | 543(H)×317.4(V) mm |
| območje okvirja | 530.2(H)×299.6(V) mm |
| zdravljenje | Antiglare (Haze 25%), Hard coating (3H) |
| svetilnost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 8/7 (Typ.)(Tr/Td) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način delovanja | AAS, Normally Black, Transmissive |
| podpira barvo | 16.7M 72% NTSC |
| Izvor svetlobe | WLED , 30K hours , W/O Driver |
| utež | 2.71Kgs (Typ.) |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (2 ch, 8-bit) , 30 pins Connector |
| napajanje | 5.0±0.5V |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
